INDIA'S 1ST CNC SLOTTING MACHINE
CNC Slotting Machine DS-8 to DS-40 Series
Price: On Request
A CNC Slotting Machine is a precision-engineered industrial machine used for cutting slots, grooves, keyways, and internal profiles in metal components with high accuracy. Controlled through Computer Numerical Control (CNC) technology, the machine performs automatic machining operations based on programmed instructions, reducing manual effort and improving production efficiency.
CNC Slotting Machines are widely used in industries such as automotive, aerospace, gear manufacturing, heavy engineering, and tool rooms for producing complex internal and external slotting operations. These machines deliver consistent performance, smooth finishing, and precise dimensional accuracy even in high-volume production environments.
Equipped with advanced control systems, rigid machine structures, and high-speed tooling capabilities, CNC Slotting Machines ensure reliable operation, reduced machining time, and minimal material wastage. They can handle a wide range of materials including steel, cast iron, aluminum, brass, and other industrial metals.
Performance Highlights
Features
- New Extra Heavy Duty Slotting Machine.
- Accuracy: Between 0.01 TO 0.03 as Per IS Standards.
- Raim Hardened and Precision Ground.
- Models: DS 8 CNC, DS 10 CNC, DS 12 CNC, DS 18 CNC and DS 24 CNC.
- CNC Axis Available: 1 Axis (X), 2 Axis (X & Y) and 3 Axis (X, Y and Rotary).
- Centralized Lubrication System.
- Absolute Servo Motors With Rolled Double Nut Ball Screw For Best Cutting Accuracy And Long Life.
- Easy to use Fully Dedicated Controller System.
- India's 1st CNC Slotting Machine.
- Quite robust and rigid construction to avoid vibrations.
- Machine is made with graded casting which is properly seasoned for at least 6 to 8 months.
- Quick return movement to save idle time.
- All gears are made of EN series steel, properly cut on hobbing and gear shaper machine.
- Rocker arm mechanism operation.
Machine Range
Technical Specifications
| Model | DS-8 CNC | DS-10 CNC | DS-12 CNC | DS 14 CNC | DS 18 CNC | DS 24 CNC |
| Maximum Stroke | 250 (10") | 300 (12") | 350 (14") | 400 (16") | 500 (20") | 600 (24") |
| Rotary Table (A) | 330 (13") | 380 (15") | 460 (18") | 500 (20") | 600 (24") | 762 (30") |
| Longitudinal Movement (B) | 250 (10") | 300 (12") | 350 (14") | 400 (16") | 450 (18") | 600 (24") |
| Cross Movement (C) | 200 (8") | 250 (10") | 300 (12") | 350 (14") | 400 (16") | 450 (18") |
| Cutting speed of ram | 60-90 | 40-60 | 40-60 | 20-54-80 | 20-54-80 | 15-45-65 |
| Ram Adjustment (D) | 250 (10") | 250 (10") | 300 (12") | 350 (14") | 460 (18") | 500 (20") |
| Distance between Table to End of Ram (E) | 355 (14") | 430 (17") | 480 (19") | 550 (22") | 635 (25") | 762 (30") |
| Distance between the Tool to Main Column (F) | 300 (12") | 380 (15") | 400 (16") | 480 (19") | 550 (22") | 600 (24") |
| Main H.P Required | 2 HP | 2 HP | 3 HP | 5 HP | 7.5 HP | 7.5 HP |
